Connecting a Github repo to a R project, Dockerize R Shiny application, and Github actions

For this blog post, I plan on discussing the following topics:

  1. Connecting a Github repository to a R project
  2. Writing a Dockerfile for a R Shiny application
  3. Setting up Github actions with the Docker image for the R shiny application

Connecting a Github repository to a R project

In order to get the R project to Github, first go to Github and log in. Once logged in, click on the + icon and click New Repository. From here, make a repository name and click on “Add a README file”. Then, click on the green code icon and copy the https. It should look something like this: https://github.com/your-github-username/your-github-repository.git. You should copy the https.

Now open up R studio. On the top left hand corner, click File, then New Project. There should be three options: New Directory, Existing Directory, and Version Control. Click on Version Control. Then hit Git. Now paste your https onto Repository URL and the Project directory name should prepopulate. Now if you don’t like where the subdirectory is for where the R project is being stored, you can change the directory by clicking on browsing. Once that is done, click on Create Project.

If you can get through all the steps mentioned above, you have successfully connected the Github repository to the R project.

Adding R files to the R project and sending R files to the Github repository

If you want to add R files, you would first create the R files:

  • R scripts(ui.R, server.R, app.R, etc.)
  • R markdown
  • etc.

From here, find the terminal tab and run the following commands to add your new files to the Github repository:

git add -A - Add the changed files

git commit -m "Whatever message you want to put in here" - Commit the changed files

git push - Push the changed files onto Github.

Writing a Dockerfile for a R shiny application

Docker is great for deploying and sharing your projects with others. Check out the following links to learn more(Links can be found in References):

  1. https://jsta.github.io/r-docker-tutorial/
  2. https://juanitorduz.github.io/dockerize-a-shinyapp/
  3. https://blog.sellorm.com/2021/04/25/shiny-app-in-docker/

Now assuming you have the following project folder structure below:

your-project.Rproj
your-script.R
README.md

You would need to create new R files for the R shiny application. Create one R file called ui and another one caleld server. The output of the files should look something like this:

ui.R
server.R

Once that is done, we need to create a Dockerfile.

Docker

To create a docker image, we would need to create a Dockerfile. To do this, click on the plus icon on the top left corner on R studio, and click on Text File. Then name the Text File to Dockerfile and make sure it is in the same directory as the ui.R and the server.R.

Now your Dockerfile should contain something like this:

# get shiny serves plus tidyverse packages image
FROM rocker/shiny-verse:latest
# system libraries of general use
RUN apt-get update && apt-get install -y \
    sudo \
    pandoc \
    pandoc-citeproc \
    libcurl4-gnutls-dev \
    libcairo2-dev \
    libxt-dev \
    libssl-dev \
    libssh2-1-dev
# install R packages required
# (change it dependeing on the packages you need)
RUN R -e "install.packages('shiny', repos='http://cran.rstudio.com/')"
RUN R -e "install.packages('shinydashboard', repos='http://cran.rstudio.com/')"
RUN R -e "install.packages('DT', repos='http://cran.rstudio.com/')"
RUN R -e "install.packages('plotly', repos='http://cran.rstudio.com/')"
# copy the app to the image
COPY r-shiny-dashboard.Rproj /srv/shiny-server/
COPY ui.R /srv/shiny-server/
COPY server.R /srv/shiny-server/
# select port
EXPOSE 3838
# allow permission
RUN sudo chown -R shiny:shiny /srv/shiny-server
# run app
CMD ["/usr/bin/shiny-server.sh"]

Note: I am still in the process of getting my Dockerfile to work properly since I got an error

Now in order to build the docker image, we can run on the console: docker build -t my-shiny-app .. And to create a container just run: docker run --rm -p 3838:3838 my-shiny-app.

From here, find the terminal tab and run the following git commands from above to add your new files to the Github repository.

Setting up Github actions with the Docker image for the R shiny application

Once you get your dockerfile with your R shiny application files onto Github, go to Action. From here, click on the “Set up this workflow” for Docker Image.

Note: I need to do some more research on the Docker Image and Containers.

Once that is done, click on start commit, and docker-image.yml file should be created. Don’t worry too much about the details, since I plan on talking about this in another blog post.

Now, if you go back to Actions, you should see a log saying Create docker-image.yml. If you click on that and click on the build, you can see that it is building the docker image.

Sidenote

Other than that, I need to do more research on this Github Actions optins for docker image and docker containers. Also, I need to figure out why I am getting an error for running for a dockerfile.

References:

  1. https://jsta.github.io/r-docker-tutorial/
  2. https://juanitorduz.github.io/dockerize-a-shinyapp/
  3. https://blog.sellorm.com/2021/04/25/shiny-app-in-docker/
Written on August 6, 2021
